THINGSBOARD installation tutorial via DOCKER

Tutoriel installation THINGSBOARD ce via DOCKER

Equipe Sparwan |

Following our article on the presentation of the Thingsboard IoT platform, we will now see how to install Thingsboard CE on a server via Docker

Thingsboard CE via Docker



docker-logo 5wuESeKPnPQZ_cxoO473189V2-gCDA13IJ4RdsoMuyZsXKki4-fmEejU5lkephjm0KlerUsrvAmM3Eh7rlnL5qunYZMmbB6dhbjaltJs_YeVmgOCMRdZ3dcLJXL8zd1LDGAKNdQWPWx95BGYZXt _Bja6_YbvoGD6KSg3xFyOHIloDgsUlJbsc2wcqQ



Here are the instructions for installing Thingsboard via Docker. If you are interested in this method, but you do not yet have a Docker server, you can refer to our tutorial: Docker installation tutorial

Please note, this method uses the Docker Compose extension . If you don't have it installed, you can follow these instructions.



Different types of Docker images for Thingsboard



Depending on the database used, there are three types of ThingsBoard single-instance Docker images:

  • Thingsboard/tb-postgres - Single instance of ThingsBoard with PostgreSQL database.

Recommended option for small servers with at least 1 GB of RAM and minimal load (a few messages per second). 2 to 4 GB is recommended.

  • Thingsboard/tb-cassandra - Single instance of ThingsBoard with Cassandra database.

The best performing and recommended option, but requires at least 4 GB of RAM. 8 GB is recommended.

  • Thingsboard/tb - Single ThingsBoard instance with embedded HSQLDB database.

Note : Not recommended for any evaluation or production use and is used for development and automated testing purposes only.

source



Choose the ThingsBoard Queue Service



ThingsBoard is capable of using various queuing systems to store messages and communication between ThingsBoard services.

There are several queuing services, which you can view here

In this tutorial, we will use the Kafka queue service with a Postgres database



Docker Compose YML file



In order to create Docker containers in a Stack to run Thingsboard, you must edit a docker-compose.yml file in which we will indicate the installation characteristics.

To create this file, use your favorite Linux editor, Vim or Nano for example

nano docker-compose.yml

In the editor, you can paste the code below, adapting it to your needs:

https://pastecode.io/s/ckuy6wnr

yml code

Options to modify according to your needs (optional, Thingsboard will work with the default options if the mentioned ports are available on your infrastructure):

8080:9090 - connect local port 8080 to exposed internal HTTP port 9090

1883:1883 - connect local port 1883 to exposed internal MQTT port 1883

7070:7070 - connect local port 7070 to exposed internal RPC Edge port 7070

5683-5688:5683-5688/udp - connect local UDP ports 5683-5688 to exposed internal COAP and LwM2M ports

~/.mytb-data:/data - mounts the host directory ~/.mytb-data into the ThingsBoard DataBase data directory

~/.mytb-logs:/var/log/thingsboard - mounts the host directory ~/.mytb-logs to the ThingsBoard logs directory

mytb - friendly local name of this machine

reboot: Always - automatically starts ThingsBoard on system reboot and restarts on failure.

image : Thingsboard/tb-postgres - docker image, can also be Thingsboard/tb-cassandra or Thingsboard/tb

docker-compose file

Save the .yml file and it will be time to create the folders mentioned in the file (you must therefore adapt the commands below if you have indicated custom paths in the file).



Create Thingsboard directories



mkdir -p ~/.mytb-data && sudo chown -R 799:799 ~/.mytb-data

mkdir -p ~/.mytb-logs && sudo chown -R 799:799 ~/.mytb-logs



NOTE: Replace the ~/.mytb-data and ~/.mytb-logs directories with the directories you plan to use in docker-compose.yml.



Once that's done, it's time to deploy the stack.



Launch Thingsboard



Here are the commands to launch Thingsboard.

docker-compose pull

Docker pull

docker-compose up

After running this command, you can open http://{your-host-ip}:8080 in your browser (e.g. http://localhost:8080). You should see the ThingsBoard login page. Use the following default credentials:

System administrator : sysadmin@thingsboard.org / sysadmin

Tenant Administrator : tenant@thingsboard.org / tenant

Customer User : customer@thingsboard.org / customer

Thingsboard login

You can always change passwords for each account in the account profile page.



Unpin, restart and stop



You can detach from the session terminal with Ctrl-p Ctrl-q - the container will continue to run in the background.

If something goes wrong, you can review the service logs for errors. For example, to view logs from ThingsBoard nodes, run the following command:

docker-compose logs -f mytb

To start :

docker-compose stop

To stop the container:

docker-compose start



Update and more



To update the container and to carry out other actions, you can refer to the official instructions.
